400-3000Lb ISTA Packaging Clamp Force Lab Testing Machine / Lab Testing Equipment With ASTM D6055

400-3000Lb ISTA Packaging Clamp Force Lab Testing Machine / Lab Testing Equipment With ASTM D6055
Product Details:
Place of Origin:
Brand Name:
Standards:
Model Number:
Contact Now
Detailed Product Description
MAXIMUM SPECIMEN WEIGHT:600kgWARRANTY PERIOD:1 Year
CLAMPING PRESSURE FORCE:400-3000Lb (adjustable)CLAMPING PLATE SIZE:Height 48inch X Depth 48inch
CLAMPING PLATE ADJUSTABLE HEIGHT:0~1000mmCLAMPING PLATE ADJUSTABLE WIDTH:200~2000mm
MOTOR:Panasonic Servo MotorACCURACY:Within ±5%
CLAMPING FORCE RATE:0.25-2.5mm/sec (according ISTA 6- SAMS CLUB)FORCE CORRECTOR:It Displays Force Value And Is Used To Calibrate Clamping Force.
CALIBRATION ACCURACY:±1% F.SDEVICE WIDTH:Less Than 2.5m
POWER:220v/ 60HzALL WEIGHT:2000kg
HIGH LIGHT:

electronic lab equipment

laboratory testing equipment


400-3000Lb ISTA Packaging Clamp Force Lab Testing Machine With ASTM D6055



The usage:
The Lab clamp testing equipment simulates the process the schnabel car discharge the package, during this process, the clamping force of the both boards will affect the package and cargo. And this test is to evaluate the resistance property of the package toward this clamping force.

Main parameter:

ItemDescription
Max. Force400~3000Lb
Maximum specimen weight600kg (can be customized)
Load cell4 load cell for highest accuracy
Control systemTouch screen controller, Windows 7, RS-232 interface
MotorPanasonic servo motor w/ DC variable speed drive system, high-precision mechanical ball screw rod
Force readingkgf, Ibf, N, KN, T etc
Load cell Resolution1/250,000
Load Precisionwithin ±0.25%
Parallelism of PlatensParallel within ±2.5mm
Clamping plate sizeHeight 48inch X depth 48inch
Clamping plate adjustable height0~1000mm
Clamping plate adjustable width200~2000mm
Base plate dimension2200 X 2100mm
Test speed0.25-2.5mm/sec (according ISTA 6- SAMS CLUB)
SoftwareTM 2101
Data displayLoad, displacement, speed, loading rate and elapsed time
FunctionThe clamp can be up and down
Clamping plate requirementMake the two clamping boards flat and non-deform under work condition (2000 Pounds) and make clamping boards’ parallel and clamping board and land vertical. Clamping board is thicker than 25mm.
Safety features

E-Stop
Over-load protection
Upper and lower limit switches
Load sensor with automatic retreat
